KCT-1245WZ 12 Axis camless CNC versatile spring rotating forming machine


  KCT-1245WZ 12-axis camless CNC versatile spring rotating forming machine, referred to as 4.5mm camless spring machine, machining line diameter φ1.2-4.5mm, suitable for the production of various precision compression spring, tension spring, torsion spring, scroll spring, tower spring, flat wire springs, special-shaped spring and molding line and other products, widely used in furniture, mold, machinery, agricultural machine, motorcycle, automobile, railway and aviation etc..


     机 型    Model    KCT-1245WZ
     轴 数    Axis Count    12 Axis
     加工线径    Wire Size Range    φ1.2-4.5mm
     最大弹簧外径         Max Outside Diameter    φ120mm
     最大送线速度    Max Feeding Speed    120m/min
     旋绕比    Spring Index    4
     送线轮组数    Wire Feeding Wheel Count        4 pairs(组)
     送线伺服电机    Feeding Servo Motor    4.4kw
     成形伺服电机    Forming Servo Motor    1.3kw*8
     转芯伺服电机    Quill Servo Motor    1.3kw
     转线伺服电机    Wire Rotation Servo Motor    4.4kw
     卷曲伺服电机    Spinner Servo Motor    1.0kw
     成形减速器    Reducer Of Wire Forming    VRB115 Ratio 1:15
     转线减速器    Reducer Of Wire Rotation    VRB090 Ratio 1:10
     卷曲减速器    Spinner Reducer    VRB140 Ratio 1:3
     机器尺寸    Dimension(L*W*H)    2400x1600x1900mm
     机器重量    Weight    5000kg
     电 源    Power AC    3-380VAC 50Hz


  Our company's KCT-1245WZ 12-axis camless CNC versatile spring rotating forming machine adopts Taiwan Windows7 operation control system, reference imported from Japan Yaskawa servo motor, using the unique non cam and no arm design tool are controlled independently by eight servo motors, the turret eight shaft, wire feeding shaft, a shaft, a rotating core transfer line the shaft and the shaft of a curl, a crank connecting rod forming system, wire feeding system, transfer system, straightening system and rotary core system etc.. In addition, the machine can be equipped with hydraulic scissors device, cutting noise is small, the damage to the mandrel and the machine is zero; at the same time also can be equipped with multi-function manipulator, not only has the characteristics of fast forming, accurate and stable performance, but also more convenient and easy to operate.
